2ZR-FE ENGINE CONTROL  ENGINE OIL TEMPERATURE SENSOR  REMOVAL


PROCEDURE

Hide 89429F 1.REMOVE ENGINE OIL TEMPERATURE SENSOR

a.

Disconnect the engine oil temperature sensor connector.


b.
A322445C01
1.271,0.427 1.604,0.427 1.604,0.427 1.771,0.74 true 1.083,0.333 1.281,0.552 0.198,0.219 10 true *a
*a 19 mm Deep Socket Wrench


Using a 19 mm deep socket wrench, remove the engine oil temperature sensor from the timing chain cover sub-assembly.

NOTICE:

If the engine oil temperature sensor has been struck or dropped, replace it.



c.

Remove the gasket from the engine oil temperature sensor.
